Chatsworth 1928 Antique Brass Traditional Shower with Concealed Valve, 8" Head + Handset Large Image
Chatsworth 1928 Antique Brass Traditional Shower with Concealed Valve, 8" Head + Handset  Profile La
Chatsworth 1928 Antique Brass Traditional Shower with Concealed Valve, 8" Head + Handset  Feature La
Chatsworth 1928 Antique Brass Traditional Shower with Concealed Valve, 8" Head + Handset Large Image

Chatsworth 1928 Antique Brass Traditional Shower with Concealed Valve, 8" Head + Handset

Part No.: CH63VABPK1

£399.95

In Stock

View in Real Homes

Overview

Chatsworth 1928 Antique Brass Traditional Triple Concealed Thermostatic Shower Valve with 8" Head + Handset

The Chatsworth 1928 antique brass concealed thermostatic shower system brings substantial elegance to the modern bathroom. The concealed triple shower valve offers thermostatic showering via three easy-to-operate controls. Operates two outlets separately or simultaneously.

Concealed valve comes supplied with a matching wall mounted antique brass 8 inch rose shower head and shower handset with parking bracket, hose.

The classic style of this antique brass effect concealed shower valve adds a touch of sophistication and elegance in any bathroom. Manufactured using high quality materials, our range of traditional shower valves will look outstanding in any bathroom.

Shower Valve Details
  • Height: 280mm
  • Width: 130mm
  • Type: Concealed Valve
  • Style: Traditional
  • Range: Chatsworth 1928
  • Colour/Finish: Brushed Antique Brass
  • Manufactured from highly durable brass
  • Water Pressure: 0.5 bar to 5 bar
  • Wall mounted
  • Thermostatically controlled
  • Classic face plate, lever and cross head handles
  • Finished in a high quality, corrosion resistant antique brass
  • Separate controls for temperature and flow.
  • Operates two outlets separately or simultaneously - 2 Outlets
  • Suitable for modern pressurised plumbing systems.
  • Can be fitted vertically or horizontally.
  • Hot water temperature 55 to 85 Degrees
  • With gravity fed systems a pump will be required, we recommend a universal or negative head pump
Shower Head Details
  • Diameter: 200mm
  • Shower arm length: 322mm
  • With Swivel ball joint
  • Style: Traditional
  • Colour/Finish: Brushed Antique Brass
  • Material: Brass
  • Wall mounted
  • Overhead rainfall shower head
  • Pressure requirement 0.5 bar minimum
  • Finished in a high quality, corrosion resistant antique brass
  • Classic design - perfect for vintage-inspired bathrooms
  • Installation of the arm requires rear access behind the wall.
Shower Handset Details
  • Height: 188mm
  • Width: 55mm
  • Depth: 80mm
  • Type: Outlet Elbow with Parking Bracket, Flex & Handset
  • Finish: Brushed Antique Brass
  • Material: Brass Internals
  • Style: Traditional
  • 1/2" BSP connections
  • Outlet elbow covers unsightly fittings
  • Suitable for use with concealed shower valves
  • 1.5m flexible hose
  • Wall mounted
  • Suitable for water pressure systems of 0.2 bar and above
  • Finished in a high quality, corrosion resistant antique brass
  • Installation requires rear access behind the wall.

All measurements are approximate

Product images are for illustrative purposes only and may differ from the actual product.

Guarantee: 3 Year (1 year guarantee on serviceable parts for example: internal components such as check valves and cartridges, 2 year guarantee on coloured finish)

Comprises


(1) Antique Brass Traditional 8" Apron Rose Shower Head
(1) Antique Brass Wall Mounted Arm
(1) Antique Brass Triple Concealed Shower Valve
(1) Antique Brass Outlet Elbow with Parking Bracket, Flex & Handset

Gravity Fed Systems:
If you live in an older property there’s a good chance you have a low pressure gravity-fed system. This shower valve requires a minimum pressure of 0.5 bar therefore we recommend installing a negative or universal pump (sold separately). Please note: Positive pumps will not work.

Product Overview

Dimension image
Dimension image
Dimension image
Dimension image
