Urban Horizontal Radiator - White - Double Panel (1600mm Wide) 608mm High

Urban Horizontal Radiator - White - Double Panel (608x1600mm)

Stay cosy with this eye catching Urban Horizontal Radiator. This modern take on the traditional column radiator embraces minimalist design, with a crisp white finish and flat rectangular tubes that provide exceptional heat output. Thanks to its flat design, the 1600mm wide radiator doesn't protrude far from the wall, saving space in compact rooms. It can also be fitted either horizontally or vertically if needed, so you can tailor it to match your home. It comes supplied with matching white horizontal brackets for a simple installation.

Product Details:

• Height: 608mm
• Width: 1600mm
• Depth: 61mm
• Projection from wall: 103mm
• Size, type and position of connections: 1/2" FI BSP
• Dry Mass: 46.6kg
• Content: 15.6lt
• BTU T50: 6225
• ∆ Watt T50: 1826°C
• Max Operating Pressure: 10 Bar
• Colour: White
• Type: Double
• Tube Size: H68xD12mm
• Columns: 8
• Features:
• Rectangular tubes provide exceptional heat output.
• Can be fitted horizontally or vertically.
• Supplied with matching white horizontal brackets.
• Pipe centres when mounted horizontally: 1550mm.

Note:

Blocker requires knocking out for horizontal installation - Refer to line drawings.
Images are for illustrative purposes only. All measurements are approximate.
We recommend pipework is not installed until receipt of radiator or heated towel rail. Radiator valves are not supplied but can be purchased separately.
Guarantee: 5 Year
