Chatsworth Traditional Crosshead Top Outlet Thermostatic Bar Shower Valve

Part No.: EG-LY-61B

£109.95

|

Available Stock due 7th Nov

Overview

Chatsworth Traditional Crosshead Top Outlet Thermostatic Bar Shower Valve in Chrome

The Chatsworth exposed thermostatic bar valve with top outlet is part of our traditional collection of bathroom products. It features classic styling with a chrome finish and is constructed from solid brass. The Chatsworth bar valve has two cross-head tap head controls with classic white indices: one controls the flow, and the other controls the temperature. Equipped with the latest anti-scald technology, the valve comes pre-set to a safe and optimal 38°C. You can easily adjust this by holding down the safety push-and-click button on the handle. The valve is designed to be used with a rigid riser kit (not included).

Product Details:

  • Width: 300mm
  • Depth: 100mm
  • Height: 40mm
  • Colour/Finish: Polished Chrome
  • Material: Solid Brass Internals
  • Style: Traditional
  • Type: Bar Shower Valve
  • Handles: Cross-head
  • Ceramic White Indices
  • Mounting: Surface / Wall Mounted
  • Outlet: Top Outlet
  • Thermostatic shower control valve for comfort and safety
  • Built-in anti-scald device
  • Separate controls for temperature and flow
  • Easy installation
  • Factory pre-set temperature: 38°C
  • Durable and dependable
  • Distance between pipe inlet centers: 150mm
  • Water Pressure: 0.5 bar to 5 bar
  • Outlet size: 15 mm (1/2" BSP)



Guarantee: 5 years (1 year on serviceable parts, e.g., internal components such as check valves and cartridges).

Please note that the product images are for illustration purposes only, and all measurements are approximate.

Gravity Fed Systems: If you live in an older property, there’s a good chance you have a low-pressure gravity-fed system. This shower valve requires a minimum pressure of 0.5 bar; therefore, we recommend installing a negative or universal pump (sold separately). Please note that positive pumps will not work.

Product Overview

Chatsworth Traditional Crosshead Top Outlet Thermostatic Bar Shower Valve

1 Question

can this be fitted with connection undrneath

Asked by Michael

ANSWER

Shaun replied on 23rd July 2019

Hi there Michael, This top outlet shower valve should not be used with the connection at the bottom. For a bottom outlet version, please click the link below or type in part number 61AXSV into our search bar. Both of these valves require the hot feed on the left and cold feed on the right. /chatsworth-traditional-crosshead-bottom-outlet-thermostatic-bar-shower-valve Hope this helps.
