Urban Horizontal Radiator - White - Single Panel (1600mm Wide)

Urban Horizontal Radiator - White - Single Panel (1600x304mm)

This sleek single panel Urban Horizontal Radiator makes a stunning minimalist statement with its slim profile, making it suitable for smaller bathrooms and cloakrooms. A smooth white finish gives this 1600mm wide flat panel horizontal radiator a versatile look that will work equally well in both modern and traditional bathrooms. Not only is it designed with durability in mind, but this white horizontal radiator also offers exceptional heat output – it’ll warm your room up in next to no time. It’s supplied with wall brackets for quick and easy installation.

Product Details:

• Width: 1600mm, Height: 304mm, Depth: 49mm
• Size, type and position of connections: 1/2" FI BSP
• Dry Mass: 12.7kg
• Content: 4.1lt
• Heat Output (BTU T30): 954
• Heat Output (Watt T30): 279W
• Heat Output (BTU T50): 1944
• Heat Output (Watt T50): 571W
• Max Operating Pressure: 10 Bar
• Projection from wall: 55mm
• Colour: White (RAL 9016)
• Type: Single
• Tube Size: W68xD12mm
• Columns: 4 Rectangular tubes provide exceptional heat outputs
• Supplied with matching white wall brackets for horizontal mounting
• Tested and Certified BS EN 442-1 Standards UKCA / CE Marked ISO9001:2015 Registered Manufacturer

Note:

Blocker requires knocking out for horizontal installation - Refer to line drawings.

Images are for illustrative purposes only. All measurements are approximate.

We recommend pipework is not installed until receipt of radiator or heated towel rail. Radiator valves are not supplied but can be purchased separately.

Guarantee: 5 Year
