Bristan - Qube Thermostatic Inline Vertical Shower Pole w/ Integral Diverter to Handset
Part No:QU-VSHXSPDIV-C
Discontinued
Product Information
Bristan - Qube Thermostatic Inline Vertical Shower Pole w/ Integral Diverter to Handset
The Qube shower valve has a wonderful modern design. Brass construction provides superior durability and conforms to BS EN 248 standards. This amazing valve trim includes lots of features and is suitable for all plumbing systems, an amazing addition to any bathroom.
Features
Additional Information
Guarantee: 5 years covering manufacturing faults
The Qube shower valve has a wonderful modern design. Brass construction provides superior durability and conforms to BS EN 248 standards. This amazing valve trim includes lots of features and is suitable for all plumbing systems, an amazing addition to any bathroom.
Features
- Product Code: QU VSHXSPDIV C
- Finish: Chrome
- Product Type: Contemporary
- Construction: Bodies are of all brass construction
- Valve Type: ¾’’, ¼ turn inline ceramic disc valve
- Cartridge Type: Thermostatic cartridge
- Supply: Suitable for all plumbing systems, preferably balanced
- Inlet Connections: 15mm push-fit integrated into backplate
- Outlet Connection: ½” BSP
- Water Pressure: Min 1.0 bar, Max. 5.0bar
- Dimensions for Fitting: 45mm inlet centres
Additional Information
- Thermostatic cartridge maintains showering temperature to +/- 1oC by compensating for changes in the incoming water temperature and pressure giving the stable outlet temperature.
- Automatic shut off in the event of hot or cold water supply failure, thus reducing the risk of scalding.
- Factory set to a maximum of 38oC to eliminate the ability to select an unsafe temperature - this can be manually over-ridden up to a maximum 46oC to suit user preference.
- Dual control – flow and temperature are controlled by separate handles, giving accurate control of both
- Chrome plated to BS EN 248
- Swivel overhead shower rose and handset with single function rub clean nozzles
- Supplied with 1.5m shower hose
- With self cancelling diverter: pull diverter out to switch from handshower to overhead shower. Reverts back automatically when shower valve is turned off.
Guarantee: 5 years covering manufacturing faults
