Grohe Solido Compact Bau Ceramic Rimless 5-in-1 Pack

Grohe Solido Compact Bau Ceramic Rimless Wall Hung Toilet with Sail Flush Plate, Concealed Cistern + Frame (5 in 1 Bundle)

The Grohe Solido Compact Bau Ceramic Rimless 5-in-1 Pack offers a complete solution for a wall mounted toilet and leaves nothing to be desired. It comes complete with the Bau Ceramic wall-hung WC and the stylish Sail flush plate in gleaming GROHE StarLight chrome finish, wall brackets and noise protection set for extra sound insulation. The WC’s rimless technology gives germs nowhere to hide, making cleaning easy. GROHE Whisper noise control reduces sound transmission caused by flushing to adjoining rooms. The dual flush system allows you to select a flush volume of either 3 or 6 litres and it’s possible to stop a full flush with the small button.

Pan Details

• Width: 368mm
• Projection: 531mm
• Brand: Grohe
• Range: Bau Ceramic
• Type: Wall hung WC pan
• Material: Vitreous china
• Colour: White
• Easy-clean rimless technology
• Supplied with slim WC seat with quick release action and soft close feature

Frame Details

• Height: 1135mm
• Width: 500mm
• Brand: Grohe
• For on-the-wall installations or studded walls
• Powder coated steel frame, self-supporting
• Fastening material with quick adjustment and height safety device
• 2 WC holding bolts
• Ceramic fixing Screw spacing 180/230 mm
• Outlet bend Ø 90 mm
• Depth adjustable
• Reducer Ø 90/110 mm
• Inlet and outlet
• Cistern GD 2, 6-9l
• Factory setting 6l and 3l
• Pneumatic discharge valve offering 3 modes of operation: dual flush or start/stop or single flush
• Water connection from left / right / rear or top

Flush Plate Details

• Width: 156mm
• Height: 197mm
• Depth: 11mm
• Brand: Grohe
• GROHE StarLight chrome finish
• GROHE EcoJoy technology for less water and perfect flow
• Material: ABS
• For 2-volume and start & stop actuation
• For vertical and horizontal installation
• For pneumatic drop valve AV1

5 Year Guarantee

Images are for illustrative purposes only

All measurements are approximate

Comprises

Bau Ceramic Rimless Wall Hung Pan
Bau Ceramic Slim Soft Close Seat
Sail Flush Plate Chrome
Solido Compact Frame 1.13m / 3/6L Cistern
Sound Insulation Set
