Bristan Kurve Monobloc Kitchen Sink Mixer - Chrome

Bristan kurve Monobloc Kitchen Sink Mixer - Chrome - KU-SNK-C

The elegant design of the Kurve Monobloc Kitchen Sink Mixer features sleek easy to use lever controls. Bristan's collection of modern kitchen taps offers a sleek style that will stand the test of time. Constructed with an all brass body with chrome levers, this tap is suitable for all plumbing systems.

Product Details

• Brand  Bristan
• Finish: Chrome
• Spout Height: 265mm
• Spout Projection: 195mm
• Swivel Spout
• Pipe Size - 15mm (1/2" BSP)
• 1/2” BSP Flexible Tails
• Connection Outlet: M22 Flow Straightener
• Construction - Body is of brass construction and is designed to conform to BS EN 200
• Valve Type - 1/2” Ceramic Disc Valve - 1/4 turn
• Supply - Suitable for all plumbing systems,
• minimum Dynamic Pressure (bar): 0.5 bar
• Maximum Dynamic Pressure (bar): 5.0 bar
• Maximum Hot Water Temperature °C: 60°C
• Maximum Static Pressure (bar): 10 bar
• Flow Type: Single Flow
• Includes flexible tails and fixing kit
• WRAS approved

Guarantee - 5 years covering manufacturing faults & 1 year Labour

All measurements are approximate

Mixed Flow Rates

• 0.5 Bar - 12.4 l/min
• 1 Bar - 18.3.2 l/min
• 2 Bar - 26 l/min
• 3 Bar - 32 l/min
• 5 Bar - 41 l/min
