Bristan - Artisan Thermostatic Recessed Dual Control Valve with Integral Diverter

Bristan - Artisan Thermostatic Recessed Dual Control Valve with Integral Diverter - AR3-SHCDIV-C

The Bristan Artisan range features dual control and thermostatic cartridge in sleek modern styling. This Thermostatic Recessed Dual Control Valve incorporates a diverter that diverts the water flow between shower heads, body jets or a bath filler. Flow and temperature are controlled separately giving accurate control of both.

Product Details

• Brand - Bristan
• Finishes - Chrome
• Product Type - Contemporary
• Construction - Body is of brass construction and is designed to conform to BS EN 200
• Valve Type - Ceramic disc valve
• Supply - Suitable for all plumbing conditions, preferably balanced. The inlet hot water temperature must be at least 10% above the required blend temperature.
• Inlet Connections - 15mm Compression connections
• Water Pressure - Working pressures 0.2-5.0 Bar
• Maximum Static Pressure - 10 Bar
• Chrome plated to BS EN 248
• Suitable for cavities between 45-75mm
• Minimum cold water supply temperature is 5°c
• Maximum hot water supply temperature is 80°c
• Flow rates at 0.2 Bar (open outlet without flow regulators) 8.0 l/min
• Cartridge can be accessed from the front
• WRAS approved

Guarantee - Lifetime covering manufacturing faults
